Routing Traffic Through a VPN Container on Proxmox and EdgeRouter X

My IP was blocked from Growatt’s servers recently, because I started fetching my own data from them. This didn’t make sense to me, but anyways. I can’t change my public IP and it’s only rotated every once in a while. This meant I had to be creative.

In this post, we’ll walk through setting up a Proxmox Linux container (CT) to run WireGuard with a Mullvad configuration and then configuring an EdgeRouter X to force specific devices’ traffic through that VPN container. In my example, the IoT host has a static IP of 10.10.10.71. We use firewall‑based policy-based routing (PBR) on the EdgeRouter to achieve this.

Prerequisites:

  • A Proxmox server
  • A working EdgeRouter X running EdgeOS v2.x (just my version, might work with others too)
  • A Linux CT on that Proxmox host (I was running Ubuntu)
  • A Mullvad subscription (for WireGuard configs)

Step 1: Create and Prepare the Proxmox Linux CT

  1. Create a New CT
    Use the Proxmox web interface to create a new container. In our case, we’re using an Ubuntu 22.02 image. Ensure the container is assigned a static IP on your LAN.

  2. Get Shell Access
    Once the CT is created, open the console or SSH into it.

  3. Update the System and Install WireGuard
    Update your package list and install WireGuard along with DNS tools:

    apt update
apt install wireguard wireguard-tools resolvconf -y

  4. Download and Install Your Mullvad Configuration
    Log in to your Mullvad account and add a device. Mullvad will provide you with an archive of valid WireGuard configs. Extract and place your chosen config at:

    /etc/wireguard/wg0.conf

  5. Start the WireGuard Interface
    Bring up the WireGuard interface with:

    wg-quick up wg0

    Then, confirm it’s active by checking your public IP:

    curl ifconfig.me

    The returned IP should match your chosen Mullvad VPN server’s exit IP.

  6. Enable IP Forwarding
    To allow the CT to forward traffic (necessary for VPN gateway functionality), enable IP forwarding:

    echo "net.ipv4.ip_forward=1" >> /etc/sysctl.conf
echo "net.ipv6.conf.all.forwarding=1" >> /etc/sysctl.conf
sysctl -p

  7. Set Up NAT Masquerading
    Configure iptables to masquerade outbound traffic on the WireGuard interface:

    iptables -t nat -A POSTROUTING -o wg0 -j MASQUERADE

  8. Add a Policy Routing Rule for Forwarded Traffic
    You can add an IP rule on the CT so that traffic from a specific host (my client at 10.10.10.71) uses an alternate routing table. For example:

    ip rule add from 10.10.10.71/32 table 100

    (Later, you can configure table 100 with a default route via wg0 if you want to affect only forwarded traffic.)

Step 2: Configure the EdgeRouter X for VPN Routing

I wanted the EdgeRouter to send all traffic from a specific IoT device (10.10.10.71) to our VPN container at 10.10.10.70.

  1. Enter Configuration Mode on the EdgeRouter:

    configure

  2. Add Firewall Modify PBR Rules
    Create a rule that matches the client’s IP and directs its traffic to an alternate routing table. For our example, we’re using table 100 (which must have a default route pointing to 10.10.10.70). For host 10.10.10.71, run:

    set firewall modify PBR rule 10 description "Route IoT 10.10.10.71 via VPN"
set firewall modify PBR rule 10 source address 10.10.10.71/32
set firewall modify PBR rule 10 modify table 100

    (You can replicate similar rules for additional IP addresses by using different rule numbers.)

  3. Commit and Save the Changes:

    commit
save

  4. Apply the PBR Rules to the LAN Interface
    Attach the modify group (named PBR) to the inbound direction of your LAN interface. For example, if your LAN is on the eth1 interface:

    configure
set interfaces eth1 firewall in modify PBR
commit
save
exit

    This ensures that traffic arriving on the LAN interface matching our PBR rule (source 10.10.10.71) is routed according to table 100.

Step 3: Verification and Testing

Test the VPN Functionality:
Inside the CT and on the other client as well, run:

curl ifconfig.me

Confirm that it shows your Mullvad server’s exit IP.

Conclusion

Pretty easy, wasn’t it? If you encounter any problems, please check again if you have replaced all IP addresses with your own.
